Laser-cut helical screw piles manufactured in Carman, Manitoba. Hot-dip galvanized for superior corrosion resistance and built to perform in Manitoba's challenging soils and deep frost conditions. We proudly serve Winnipeg, Brandon, Steinbach, Portage la Prairie, Winkler and communities across Saskatchewan, Alberta, Ontario, as well as North Dakota, Minnesota and the nearest US states. Fast, low-impact installation with immediate load-bearing capacity — no excavation or concrete required.
2 3/8" Screw Piles
Ideal for lightweight to medium-duty applications including decks, sidewalks, steps, and small structures. Compact helical design provides excellent soil penetration and frost heave resistance common in Manitoba.
Galvanized steel • 5,000–10,000 lb typical compressive capacity range • Fast machine installation.
Download 2 3/8" specification sheet →
2 7/8" Screw Piles
Excellent choice for solar arrays, larger decks, and light commercial foundations. Strong torque resistance and customizable helices perform well in variable and tough Manitoba terrains.
Up to ~20,000+ lb capacity depending on torque. Year-round installation with minimal site disturbance.
3 1/2" Screw Piles
Mid-range strength perfect for house additions, garages, sunrooms, and small to medium residential builds. Deep-penetrating helices provide excellent stability against settlement in Manitoba's variable soils.
25,000–40,000 lb range • Hot-dip galvanized • Simple hydraulic installation.
4 1/2" Screw Piles
Heavy-duty option for new home foundations, full structural support, and underpinning projects. Wider shaft and multi-helix configurations deliver high compressive and lateral resistance.
40,000+ lb capacity • Precision laser cut and fully galvanized for long-term durability in harsh conditions.
Download 4 1/2" specification sheet →
6 5/8" – 8 5/8" Screw Piles
Engineered for demanding commercial, agricultural, and multi-story projects. Large diameter shafts with substantial helices provide exceptional torque and bearing capacity in challenging sites.
50,000–100,000+ lb range • Low environmental impact installation • Ideal for remote and northern Manitoba construction.
Contact us for 6 5/8"–8 5/8" specs & custom engineering →Why Choose Liberty Laser Helical Screw Piles
Locally Manufactured in Manitoba
Precision laser-cut in the Carman area using high-quality galvanized steel. Supporting local and reducing lead times for projects across the province.
Built for Manitoba Conditions
Designed with deep frost penetration and variable soils in mind. Install year-round — even through frozen ground — with immediate load capacity.
Fast, Low-Impact Installation
No large excavations or concrete curing. Minimal site disturbance makes them ideal for residential lots, agricultural land, and remote northern communities.
Engineered & Traceable Capacities
Detailed torque-to-capacity data available for each diameter. We can provide engineering support and stamped drawings when required.
Corrosion Protection
Hot-dip galvanized after fabrication for long service life in aggressive soils and high water table areas common in parts of Manitoba.
Versatile & Reusable
Easily installed with standard equipment. Piles can often be removed and reused for temporary structures or relocated projects.
Common Applications
Service Areas — Canada & the United States
Liberty Laser manufactures and supplies helical screw piles for projects across the Prairies and beyond. Our foundations are trusted for residential, commercial, solar, agricultural, and remote construction in challenging northern climates.
Manitoba's Major Cities
- Winnipeg
- Brandon
- Steinbach
- Portage la Prairie
- Winkler
- + communities across all of Manitoba
Ontario, Saskatchewan & Alberta
- Saskatchewan (Regina, Saskatoon & province-wide)
- Alberta (Calgary, Edmonton & throughout)
- Ontario (Toronto, Ottawa & rural/northern areas)
- Full provincial coverage for foundations and fabrication
10 Nearest US States
- North Dakota
- Minnesota
- South Dakota
- Montana
- Wisconsin
- Iowa
- Nebraska
- Wyoming
- Michigan
- Idaho
Upper Midwest, Plains & Mountain states
Technical Specifications & Downloads
Detailed axial capacity tables (compression & tension) versus installation torque are available for each pile diameter. Contact us for custom lengths, helix configurations, or engineered stamped drawings.
For 6 5/8"–8 5/8" and custom engineered piles, please request documentation directly.
Precision Manufacturing & Quality
Every Liberty Laser screw pile is produced using advanced laser cutting technology for consistent helix geometry and shaft quality. Components are hot-dip galvanized after fabrication for maximum corrosion protection. Our team performs rigorous in-process and final inspections to ensure each pile meets demanding structural and durability requirements for Manitoba projects.
Free quotes • CAD drawings available • Serving Winnipeg, Brandon, Steinbach, Saskatchewan, Alberta & Ontario
